Langmuir decay instability for localized Langmuir wave packets in two-dimensional inhomogeneous plasmas

Yongxin Li; Yong Chen; Han Wen; Shang Tan; Yugu Chen; Chengzhuo Xiao

doi:10.1063/5.0314537

Volume 11 Issue 4

Jul. 2026

Turn off MathJax

Article Contents

Article Navigation > Matter and Radiation at Extremes > 2026 > 11(4): 047403

Yongxin Li, Yong Chen, Han Wen, Shang Tan, Yugu Chen, Chengzhuo Xiao. Langmuir decay instability for localized Langmuir wave packets in two-dimensional inhomogeneous plasmas[J]. Matter and Radiation at Extremes, 2026, 11(4): 047403. doi: 10.1063/5.0314537

Citation:

Yongxin Li, Yong Chen, Han Wen, Shang Tan, Yugu Chen, Chengzhuo Xiao. Langmuir decay instability for localized Langmuir wave packets in two-dimensional inhomogeneous plasmas[J]. Matter and Radiation at Extremes, 2026, 11(4): 047403. doi: 10.1063/5.0314537

Citation:

Yongxin Li, Yong Chen, Han Wen, Shang Tan, Yugu Chen, Chengzhuo Xiao. Langmuir decay instability for localized Langmuir wave packets in two-dimensional inhomogeneous plasmas[J]. Matter and Radiation at Extremes, 2026, 11(4): 047403. doi: 10.1063/5.0314537

PDF( 8718 KB)

Langmuir decay instability for localized Langmuir wave packets in two-dimensional inhomogeneous plasmas

doi: 10.1063/5.0314537

Yongxin Li^1
,,
Yong Chen^{2
,
,},
Han Wen^1
,,
Shang Tan^1
,,
Yugu Chen¹,
Chengzhuo Xiao^{1
,
,}

1.
School of Physics and Electronics, Hunan University, Changsha 410082, China
2.
School of Electrical and Information Engineering, Anhui University of Science and Technology, Huainan, Anhui 232001, China

More Information

Corresponding author: a)Author to whom correspondence should be addressed: xiaocz@hnu.edu.cn
Received Date: 2025-11-30
Accepted Date: 2026-05-05

Available Online: 2026-07-24

Publish Date: 2026-07-24

Abstract

Abstract

The Langmuir decay instability (LDI) is a key saturation mechanism for stimulated Raman scattering (SRS) in inertial confinement fusion plasmas. However, a quantitative characterization of the two-dimensional angular spectrum of LDI in such inhomogeneous environments, particularly its dependence on the pump-wave incidence angle, remains limited. Here, we combine a k-space theoretical model with two-dimensional particle-in-cell simulations to study a localized Langmuir wave packet in a linear density gradient. Our results show that although the density gradient suppresses the overall strength of LDI, the backscattering channel (φ ≈ 180°) remains the dominant decay mode across all tested pump incidence angles. These results help clarify the multidimensional evolution of LDI in inhomogeneous plasmas and may be useful for developing more predictive models of SRS saturation in laser-fusion schemes.

The authors have no conflicts to disclose.
Conflict of Interest
Yongxin Li: Conceptualization (lead); Data curation (lead); Formal analysis (lead); Investigation (lead); Methodology (lead); Software (lead); Validation (lead); Visualization (lead); Writing – original draft (lead); Writing – review & editing (lead). Yong Chen: Formal analysis (supporting); Writing – review & editing (supporting). Han Wen: Formal analysis (supporting); Writing – review & editing (supporting). Shang Tan: Formal analysis (supporting); Writing – review & editing (supporting). Yugu Chen: Formal analysis (supporting); Writing – review & editing (supporting). Chengzhuo Xiao: Conceptualization (lead); Funding acquisition (lead); Project administration (lead); Writing – review & editing (lead).
Author Contributions
The data that support the findings of this study are available from the corresponding author upon reasonable request.

FullText(HTML)

References(48)

References

[1]	W. Huo, Z. Li, D. Yang, K. Lan, J. Liu et al., “First demonstration of improving laser propagation inside the spherical hohlraums by using the cylindrical laser entrance hole,” Matter Radiat. Extremes 1, 2–7 (2016).10.1016/j.mre.2016.02.001
[2]	A. B. Zylstra, O. A. Hurricane, D. A. Callahan, A. L. Kritcher, J. E. Ralph et al., “Burning plasma achieved in inertial fusion,” Nature 601, 542–548 (2022).10.1038/s41586-021-04281-w
[3]	J. Lindl, “Development of the indirect-drive approach to inertial confinement fusion and the target physics basis for ignition and gain,” Phys. Plasmas 2, 3933–4024 (1995).10.1063/1.871025
[4]	D. S. Montgomery, “Two decades of progress in understanding and control of laser plasma instabilities in indirect drive inertial fusion,” Phys. Plasmas 23, 055601 (2016).10.1063/1.4946016
[5]	M. Troccoli, A. Belyanin, F. Capasso, E. Cubukcu, D. L. Sivco et al., “Raman injection laser,” Nature 433, 845–848 (2005).10.1038/nature03330
[6]	J. Vieira, R. M. G. M. Trines, E. P. Alves, R. A. Fonseca, J. T. Mendonça et al., “Amplification and generation of ultra-intense twisted laser pulses via stimulated Raman scattering,” Nat. Commun. 7, 10371 (2016).10.1038/ncomms10371
[7]	S. Yampolsky, D. A. Fishman, S. Dey, E. Hulkko, M. Banik et al., “Seeing a single molecule vibrate through time-resolved coherent anti-Stokes Raman scattering,” Nat. Photonics 8, 650–656 (2014).10.1038/nphoton.2014.143
[8]	P. Michel, L. Divol, E. L. Dewald, J. L. Milovich, M. Hohenberger et al., “Multibeam stimulated Raman scattering in inertial confinement fusion conditions,” Phys. Rev. Lett. 115, 055003 (2015).10.1103/physrevlett.115.055003
[9]	Y. Zhao, Z. Sheng, S. Weng, S. Ji, and J. Zhu, “Absolute instability modes due to rescattering of stimulated Raman scattering in a large nonuniform plasma,” High Power Laser Sci. Eng. 7, e20 (2019).10.1017/hpl.2019.5
[10]	J. W. Bates, R. K. Follett, J. G. Shaw, S. P. Obenschain, J. F. Myatt et al., “Suppressing parametric instabilities in direct-drive inertial-confinement-fusion plasmas using broadband laser light,” Phys. Plasmas 30, 052703 (2023).10.1063/5.0150865
[11]	S. Tan, Q. Wang, Y. Chen, W. B. Yao, C. Z. Xiao et al., “Rescattering of stimulated Raman side scattering in nonuniform plasmas,” Matter Radiat. Extremes 9, 057402 (2024).10.1063/5.0206740
[12]	A. B. Langdon, B. F. Lasinski, and W. L. Kruer, “Nonlinear saturation and recurrence of the two-plasmon decay instability,” Phys. Rev. Lett. 43, 133 (1979).10.1103/physrevlett.43.133
[13]	N. A. Ebrahim, H. A. Baldis, C. Joshi, and R. Benesch, “Hot electron generation by the two-plasmon decay instability in the laser-plasma interaction at 10.6 μm,” Phys. Rev. Lett. 45, 1179 (1980).10.1103/physrevlett.45.1179
[14]	D. H. Froula, B. Yaakobi, S. X. Hu, P.-Y. Chang, R. S. Craxton et al., “Saturation of the two-plasmon decay instability in long-scale-length plasmas relevant to direct-drive inertial confinement fusion,” Phys. Rev. Lett. 108, 165003 (2012).10.1103/physrevlett.108.165003
[15]	W. Seka, J. F. Myatt, R. W. Short, D. H. Froula, J. Katz et al., “Nonuniformly driven two-plasmon-decay instability in direct-drive implosions,” Phys. Rev. Lett. 112, 145001 (2014).10.1103/physrevlett.112.145001
[16]	K. Kawasaki, G. Cristoforetti, T. Idesaka, Y. Hironaka, D. Tanaka et al., “Effects of hydrogen concentration in ablator material on stimulated Raman scattering, two-plasmon decay, and hot electrons for direct-drive inertial confinement fusion,” Phys. Rev. Res. 5, 033051 (2023).10.1103/physrevresearch.5.033051
[17]	C. Yao, J. Li, L. Hao, R. Yan, C. Wang et al., “Anomalous hot electron generation from two-plasmon decay instability driven by broadband laser pulses with intensity modulations,” Nucl. Fusion 64, 106013 (2024).10.1088/1741-4326/ad6c62
[18]	S. H. Glenzer, K. B. Fournier, B. G. Wilson, R. W. Lee, and L. J. Suter, “Ionization balance in inertial confinement fusion hohlraums,” Phys. Rev. Lett. 87, 045002 (2001).10.1103/physrevlett.87.045002
[19]	E. L. Dewald, F. Hartemann, P. Michel, J. Milovich, M. Hohenberger et al., “Generation and beaming of early hot electrons onto the capsule in laser-driven ignition hohlraums,” Phys. Rev. Lett. 116, 075003 (2016).10.1103/physrevlett.116.075003
[20]	H. A. Rose, D. F. DuBois, and B. Bezzerides, “Nonlinear coupling of stimulated Raman and Brillouin scattering in laser-plasma interactions,” Phys. Rev. Lett. 58, 2547–2550 (1987).10.1103/physrevlett.58.2547
[21]	D. F. DuBois, H. A. Rose, and D. Russell, “Coexistence of parametric decay cascades and caviton collapse at subcritical densities,” Phys. Rev. Lett. 66, 1970–1973 (1991).10.1103/physrevlett.66.1970
[22]	S. Depierreux, C. Labaune, J. Fuchs, D. Pesme, V. T. Tikhonchuk et al., “Langmuir decay instability cascade in laser-plasma experiments,” Phys. Rev. Lett. 89, 045001 (2002).10.1103/physrevlett.89.045001
[23]	J. P. Palastro, E. A. Williams, D. E. Hinkel, L. Divol, and D. J. Strozzi, “Kinetic dispersion of Langmuir waves. I. The Langmuir decay instability,” Phys. Plasmas 16, 092304 (2009).10.1063/1.3234245
[24]	L. Hao, R. Yan, J. Li, W. D. Liu, and C. Ren, “Nonlinear fluid simulation study of stimulated Raman and Brillouin scatterings in shock ignition,” Phys. Plasmas 24, 062709 (2017).10.1063/1.4989702
[25]	K. L. Baker, R. P. Drake, B. S. Bauer, K. G. Estabrook, A. M. Rubenchik et al., “Observation of the Langmuir decay instability driven by stimulated Raman scattering,” Phys. Plasmas 4, 3012–3020 (1997).10.1063/1.872436
[26]	J.-R. Marquès, C. Briand, F. Amiranoff, S. Depierreux, M. Grech et al., “Laser-plasma interaction experiment for solar burst studies,” Phys. Rev. Lett. 124, 135001 (2020).10.1103/physrevlett.124.135001
[27]	D. J. Strozzi, M. M. Shoucri, A. Bers, E. A. Williams, and A. B. Langdon, “Vlasov simulations of trapping and inhomogeneity in Raman scattering,” J. Plasma Phys. 72, 1299–1302 (2006).10.1017/s0022377806005599
[28]	S. J. Yang, H. B. Zhuo, Y. Yin, Z. J. Liu, C. Y. Zheng et al., “Growth and saturation of stimulated Raman scattering in two overlapping laser beams,” Phys. Rev. E 102, 013205 (2020).10.1103/physreve.102.013205
[29]	S. Depierreux, J. Fuchs, C. Labaune, A. Michard, H. A. Baldis et al., “First observation of ion acoustic waves produced by the Langmuir decay instability,” Phys. Rev. Lett. 84, 2869–2872 (2000).10.1103/physrevlett.84.2869
[30]	D. S. Montgomery, J. A. Cobble, J. C. Fernández, R. J. Focia, R. P. Johnson et al., “Recent Trident single hot spot experiments: Evidence for kinetic effects, and observation of Langmuir decay instability cascade,” Phys. Plasmas 9, 2311–2320 (2002).10.1063/1.1468857
[31]	C. G. R. Geddes, R. K. Kirkwood, S. H. Glenzer, K. Estabrook, B. I. Cohen et al., “Observation of ion wave decay products of Langmuir waves generated by stimulated Raman scattering in ignition scale plasmas,” Phys. Plasmas 10, 3422–3425 (2003).10.1063/1.1590317
[32]	H. A. Rose, “Langmuir wave self-focusing versus decay instability,” Phys. Plasmas 12, 012318 (2004).10.1063/1.1829066
[33]	S. Brunner and E. J. Valeo, “Trapped-particle instability leading to bursting in stimulated Raman scattering simulations,” Phys. Rev. Lett. 93, 145003 (2004).10.1103/physrevlett.93.145003
[34]	J. L. Kline, D. S. Montgomery, B. Bezzerides, J. A. Cobble, D. F. DuBois et al., “Observation of a transition from fluid to kinetic nonlinearities for Langmuir waves driven by stimulated Raman backscatter,” Phys. Rev. Lett. 94, 175003 (2005).10.1103/physrevlett.94.175003
[35]	J. L. Kline, D. S. Montgomery, L. Yin, D. F. DuBois, B. J. Albright et al., “Different kλD regimes for nonlinear effects on Langmuir waves,” Phys. Plasmas 13, 055906 (2006).10.1063/1.2178777
[36]	L. Yin, B. J. Albright, K. J. Bowers, W. Daughton, and H. A. Rose, “Saturation of backward stimulated scattering of a laser beam in the kinetic regime,” Phys. Rev. Lett. 99, 265004 (2007).10.1103/physrevlett.99.265004
[37]	M. N. Rosenbluth, “Parametric instabilities in inhomogeneous media,” Phys. Rev. Lett. 29, 565–567 (1972).10.1103/physrevlett.29.565
[38]	T. Fouquet and D. Pesme, “Increase of the backward Raman reflectivity caused by the Langmuir decay instability in an inhomogeneous plasma: The loss of gradient stabilization,” Phys. Rev. Lett. 100, 055006 (2008).10.1103/physrevlett.100.055006
[39]	L. F. Ziebell, R. Gaelzer, and P. H. Yoon, “Dynamics of Langmuir wave decay in two dimensions,” Phys. Plasmas 15, 032303 (2008).10.1063/1.2844740
[40]	C. Krafft, A. S. Volokitin, and V. V. Krasnoselskikh, “Langmuir wave decay in inhomogeneous solar wind plasmas: Simulation results,” Astrophys. J. 809, 176 (2015).10.1088/0004-637x/809/2/176
[41]	W. Kruer, The Physics of Laser Plasma Interactions (CRC Press, 2019), pp. 1–200.
[42]	C. S. Liu, M. N. Rosenbluth, and R. B. White, “Parametric scattering instabilities in inhomogeneous plasmas,” Phys. Rev. Lett. 31, 697 (1973).10.1103/physrevlett.31.697
[43]	R. Sentis, “Mathematical models for laser-plasma interaction,” ESAIM: Math. Modell. Numer. Anal. 39, 275–318 (2005).10.1051/m2an:2005014
[44]	V. E. Zakharov, “Collapse of Langmuir waves,” Sov. Phys. JETP 35, 908–914 (1972).
[45]	C. Z. Xiao, Q. Wang, and J. F. Myatt, “k-space theory and convective gains of stimulated Raman side scattering,” Phys. Rev. E 107, 025203 (2023).10.1103/physreve.107.025203
[46]	J.-L. Vay, A. Huebl, A. Almgren, L. D. Amorim, J. Bell et al., “Modeling of a chain of three plasma accelerator stages with the WarpX electromagnetic PIC code on GPUs,” Phys. Plasmas 28, 023105 (2021).10.1063/5.0028512
[47]	A. J. Willes, P. A. Robinson, and D. B. Melrose, “Second harmonic electromagnetic emission via Langmuir wave coalescence,” Phys. Plasmas 3, 149–159 (1996).10.1063/1.871841
[48]	C. Krafft and P. Savoini, “Electrostatic wave decay in the randomly inhomogeneous solar wind,” Astrophys. J., Lett. 964, L30 (2024).10.3847/2041-8213/ad3449
