Hexagonal diamond formation mechanism: A review

Yu Tao; Zhu Shengcai

doi:10.1063/5.0310909

Volume 11 Issue 3

May 2026

Turn off MathJax

Article Contents

Article Navigation > Matter and Radiation at Extremes > 2026 > 11(3): 033801

Yu Tao, Zhu Shengcai. Hexagonal diamond formation mechanism: A review[J]. Matter and Radiation at Extremes, 2026, 11(3): 033801. doi: 10.1063/5.0310909

Citation:

Yu Tao, Zhu Shengcai. Hexagonal diamond formation mechanism: A review[J]. Matter and Radiation at Extremes, 2026, 11(3): 033801. doi: 10.1063/5.0310909

Yu Tao, Zhu Shengcai. Hexagonal diamond formation mechanism: A review[J]. Matter and Radiation at Extremes, 2026, 11(3): 033801. doi: 10.1063/5.0310909

Citation:

Yu Tao, Zhu Shengcai. Hexagonal diamond formation mechanism: A review[J]. Matter and Radiation at Extremes, 2026, 11(3): 033801. doi: 10.1063/5.0310909

PDF( 15102 KB)

Hexagonal diamond formation mechanism: A review

doi: 10.1063/5.0310909

Yu Tao,
Zhu Shengcai^{,
,}

School of Materials, Sun Yat-sen University, Shenzhen, China

More Information

Corresponding author: a)Author to whom correspondence should be addressed: zhushc@mail.sysu.edu.cn
Received Date: 2025-11-05
Accepted Date: 2026-03-03

Available Online: 2026-05-01

Publish Date: 2026-05-28

Abstract

Abstract

As a metastable carbon allotrope, hexagonal diamond (HD) exhibits potentially superior mechanical properties to cubic diamond (CD). However, its synthesis faces significant thermodynamic and kinetic challenges. This review summarizes the critical role of computational simulations in the synthesis of HD, covering both static calculations and molecular dynamics (MD) simulations. Static calculations reveal that graphite tends to transform into CD under interface-free conditions, whereas the presence of an interface results in a lower energy barrier for the HD phase transition. With regard to MD simulations, while early shock compression simulations failed to observe HD formation, recent studies based on neural network potentials have confirmed a shock-velocity-dependent transformation pathway and have successfully obtained HD, consistent with in situ experimental results. Hydrostatic pressure simulations emphasize the importance of controlling interlayer sliding, demonstrating that strategies such as quasi-uniaxial compression can promote the preferential formation of HD. In the future, the integration of high-precision simulations with experimental approaches is expected to enable the controllable synthesis of HD, thereby advancing its applications in ultrahard materials, power electronics, aerospace, and other fields.

Conflict of Interest
The authors have no conflicts to disclose.
Tao Yu: Data curation (equal); Formal analysis (equal); Investigation (equal). Shengcai Zhu: Conceptualization (equal); Funding acquisition (equal); Investigation (equal); Methodology (equal); Project administration (equal); Resources (equal); Software (equal); Supervision (equal).
Author Contributions
Data sharing is not applicable to this article as no new data were created or analyzed in this study.

FullText(HTML)

References(68)

References

[1]	L. Yang, K. C. Lau, Z. Zeng, D. Zhang, H. Tang et al., “Synthesis of bulk hexagonal diamond,” Nature 644, 370–375 (2025).10.1038/s41586-025-09343-x
[2]	S. Ergun and L. E. Alexander, “Crystalline forms of carbon: A possible hexagonal polymorph of diamond,” Nature 195, 765–767 (1962).10.1038/195765a0
[3]	C. Frondel and U. B. Marvin, “Lonsdaleite, a hexagonal polymorph of diamond,” Nature 214, 587–589 (1967).10.1038/214587a0
[4]	F. P. Bundy and J. S. Kasper, “Hexagonal diamond—A new form of carbon,” J. Chem. Phys. 46, 3437–3446 (1967).10.1063/1.1841236
[5]	Z. Pan, H. Sun, Y. Zhang, and C. Chen, “Harder than diamond: Superior indentation strength of wurtzite BN and lonsdaleite,” Phys. Rev. Lett. 102, 055503 (2009).10.1103/physrevlett.102.055503
[6]	Y. Shang, Z. Liu, J. Dong, M. Yao, Z. Yang et al., “Ultrahard bulk amorphous carbon from collapsed fullerene,” Nature 599, 599–604 (2021).10.1038/s41586-021-03882-9
[7]	M. R. Salehpour and S. Satpathy, “Comparison of electron bands of hexagonal and cubic diamond,” Phys. Rev. B 41, 3048–3052 (1990).10.1103/physrevb.41.3048
[8]	Y. Zheng, S. Lu, C. Chen, M. Jiang, X. Li et al., “Pure hexagonal diamond with symmetry-doping properties,” ACS Appl. Mater. Interfaces 16, 52674–52681 (2024).10.1021/acsami.4c11757
[9]	R. Z. Khaliullin, H. Eshet, T. D. Kühne, J. Behler, and M. Parrinello, “Nucleation mechanism for the direct graphite-to-diamond phase transition,” Nat. Mater. 10, 693–697 (2011).10.1038/nmat3078
[10]	S. Iijima, “Helical microtubules of graphitic carbon,” Nature 354, 56–58 (1991).10.1038/354056a0
[11]	Q. Li, Y. Ma, A. R. Oganov, H. Wang, H. Wang et al., “Superhard monoclinic polymorph of carbon,” Phys. Rev. Lett. 102, 175506 (2009).10.1103/physrevlett.102.175506
[12]	J.-T. Wang, C. Chen, and Y. Kawazoe, “Low-temperature phase transformation from graphite to sp3 orthorhombic carbon,” Phys. Rev. Lett. 106, 075501 (2011).10.1103/physrevlett.106.075501
[13]	K. Umemoto, R. M. Wentzcovitch, S. Saito, and T. Miyake, “Body-centered tetragonal C4: A viable sp3 carbon allotrope,” Phys. Rev. Lett. 104, 125504 (2010).10.1103/physrevlett.104.125504
[14]	Z. Zhao, B. Xu, X.-F. Zhou, L.-M. Wang, B. Wen et al., “Novel superhard carbon: C-centered orthorhombic C8,” Phys. Rev. Lett. 107, 215502 (2011).10.1103/physrevlett.107.215502
[15]	H. Niu, X.-Q. Chen, S. Wang, D. Li, W. L. Mao et al., “Families of superhard crystalline carbon allotropes constructed via cold compression of graphite and nanotubes,” Phys. Rev. Lett. 108, 135501 (2012).10.1103/physrevlett.108.135501
[16]	A. Lazicki, D. McGonegle, J. R. Rygg, D. G. Braun, D. C. Swift et al., “Metastability of diamond ramp-compressed to 2 terapascals,” Nature 589, 532–535 (2021).10.1038/s41586-020-03140-4
[17]	V. Kvasnytsya, R. Wirth, L. Dobrzhinetskaya, J. Matzel, B. Jacobsen et al., “New evidence of meteoritic origin of the Tunguska cosmic body,” Planet. Space Sci. 84, 131–140 (2013).10.1016/j.pss.2013.05.003
[18]	T. Irifune, A. Kurio, S. Sakamoto, T. Inoue, and H. Sumiya, “Ultrahard polycrystalline diamond from graphite,” Nature 421, 599–600 (2003).10.1038/421599b
[19]	H. Sumiya, H. Yusa, T. Inoue, H. Ofuji, and T. Irifune, “Conditions and mechanism of formation of nano-polycrystalline diamonds on direct transformation from graphite and non-graphitic carbon at high pressure and temperature,” High Pressure Res. 26, 63–69 (2006).10.1080/08957950600765863
[20]	P. Németh, L. A. J. Garvie, T. Aoki, N. Dubrovinskaia, L. Dubrovinsky et al., “Lonsdaleite is faulted and twinned cubic diamond and does not exist as a discrete material,” Nat. Commun. 5, 5447 (2014).10.1038/ncomms6447
[21]	V. A. Greshnyakov, E. A. Belenkov, and M. M. Brzhezinskaya, “Theoretical investigation of phase transitions of graphite and cubic 3C diamond into hexagonal 2H diamond under high pressures,” Phys. Status Solidi B 256, 1800575 (2019).10.1002/pssb.201800575
[22]	A. P. Jones, P. F. McMillan, C. G. Salzmann, M. Alvaro, F. Nestola et al., “Structural characterization of natural diamond shocked to 60 GPa; implications for Earth and planetary systems,” Lithos 265, 214–221 (2016).10.1016/j.lithos.2016.09.023
[23]	C. G. Salzmann, B. J. Murray, and J. J. Shephard, “Extent of stacking disorder in diamond,” Diamond Relat. Mater. 59, 69–72 (2015).10.1016/j.diamond.2015.09.007
[24]	H. Ohfuji, T. Irifune, K. D. Litasov, T. Yamashita, F. Isobe et al., “Natural occurrence of pure nano-polycrystalline diamond from impact crater,” Sci. Rep. 5, 14702 (2015).10.1038/srep14702
[25]	C. L. Guillou, F. Brunet, T. Irifune, H. Ohfuji, and J.-N. Rouzaud, “Nanodiamond nucleation below 2273 K at 15 GPa from carbons with different structural organizations,” Carbon 45, 636–648 (2007).10.1016/j.carbon.2006.10.005
[26]	A. V. Kurdyumov, V. F. Britun, V. V. Yarosh, A. I. Danilenko, and V. B. Zelyavskii, “The influence of the shock compression conditions on the graphite transformations into lonsdaleite and diamond,” J. Superhard Mater. 34, 19–27 (2012).10.3103/s1063457612010029
[27]	L. A. J. Garvie, P. Németh, and P. R. Buseck, “Transformation of graphite to diamond via a topotactic mechanism,” Am. Mineral. 99, 531–538 (2014).10.2138/am.2014.4658
[28]	T. Yagi, W. Utsumi, M.-a. Yamakata, T. Kikegawa, and O. Shimomura, “High-pressure in situ x-ray-diffraction study of the phase transformation from graphite to hexagonal diamond at room temperature,” Phys. Rev. B 46, 6031–6039 (1992).10.1103/physrevb.46.6031
[29]	J. Xu, H. Mao, and J. H. Russell, “The gem anvil cell: High-pressure behaviour of diamond and related materials,” J. Phys.: Condens. Matter 14, 11549 (2002).10.1088/0953-8984/14/44/514
[30]	E. D. Miller, D. C. Nesting, and J. V. Badding, “Quenchable transparent phase of carbon,” Chem. Mater. 9, 18–22 (1997).10.1021/cm960288k
[31]	W. L. Mao, H. K. Mao, P. J. Eng, T. P. Trainor, M. Newville et al., “Bonding changes in compressed superhard graphite,” Science 302, 425–427 (2003).10.1126/science.1089713
[32]	D.-s. Chen, H.-y. Li, J.-j. Dong, and M.-g. Yao, “Synthesis of hexagonal diamond: A review,” New Carbon Mater. 40, 584–595 (2025).10.1016/s1872-5805(25)60993-0
[33]	Y.-P. Xie, X.-J. Zhang, and Z.-P. Liu, “Graphite to diamond: Origin for kinetics selectivity,” J. Am. Chem. Soc. 139, 2545–2548 (2017).10.1021/jacs.6b11193
[34]	D. Luo, L. Yang, H. Xie, S. Srinivasan, J. Tian et al., “Atomistic evidence of nucleation mechanism for the direct graphite-to-diamond transformation,” Carbon 229, 119538 (2024).10.1016/j.carbon.2024.119538
[35]	H. Xie, F. Yin, T. Yu, J.-T. Wang, and C. Liang, “Mechanism for direct graphite-to-diamond phase transition,” Sci. Rep. 4, 5930 (2014).10.1038/srep05930
[36]	X. Dong, X.-F. Zhou, G.-R. Qian, Z. Zhao, Y. Tian et al., “An ab initio study on the transition paths from graphite to diamond under pressure,” J. Phys.: Condens. Matter 25, 145402 (2013).10.1088/0953-8984/25/14/145402
[37]	P. Xiao and G. Henkelman, “Communication: From graphite to diamond: Reaction pathways of the phase transition,” J. Chem. Phys. 137, 101101 (2012).10.1063/1.4752249
[38]	S. E. Boulfelfel, A. R. Oganov, and S. Leoni, “Understanding the nature of ‘superhard graphite,’” Sci. Rep. 2, 471 (2012).10.1038/srep00471
[39]	S. Scandolo, M. Bernasconi, G. L. Chiarotti, P. Focher, and E. Tosatti, “Pressure-induced transformation path of graphite to diamond,” Phys. Rev. Lett. 74, 4015–4018 (1995).10.1103/physrevlett.74.4015
[40]	S. Fahy, S. G. Louie, and M. L. Cohen, “Theoretical total-energy study of the transformation of graphite into hexagonal diamond,” Phys. Rev. B 35, 7623–7626 (1987).10.1103/physrevb.35.7623
[41]	S. Fahy, S. G. Louie, and M. L. Cohen, “Pseudopotential total-energy study of the transition from rhombohedral graphite to diamond,” Phys. Rev. B 34, 1191–1199 (1986).10.1103/physrevb.34.1191
[42]	Z. Zeng, L. Yang, Q. Zeng, H. Lou, H. Sheng et al., “Synthesis of quenchable amorphous diamond,” Nat. Commun. 8, 322 (2017).10.1038/s41467-017-00395-w
[43]	S.-C. Zhu, G.-W. Chen, X.-H. Yuan, Y. Cheng, M.-H. Wan et al., “Key for hexagonal diamond formation: Theoretical and experimental study,” J. Am. Chem. Soc. 147, 2158–2167 (2025).10.1021/jacs.4c16312
[44]	G.-W. Chen, S.-C. Zhu, L. Xu, Y.-M. Li, Z.-P. Liu et al., “The transformation mechanism of graphite to hexagonal diamond under shock conditions,” JACS Au 4, 3413–3420 (2024).10.1021/jacsau.4c00523
[45]	X. Yuan, G. Chen, Y. Cheng, S. Zhu, F. Liu et al., “Direct synthesis of millimeter-sized hexagonal diamond from graphite,” Sci. Bull. 70, 1257–1263 (2025).10.1016/j.scib.2025.03.003
[46]	D. Chen, G. Chen, L. Lv, J. Dong, Y. Shang et al., “General approach for synthesizing hexagonal diamond by heating post-graphite phases,” Nat. Mater. 24, 513–518 (2025).10.1038/s41563-025-02126-9
[47]	G. Chen, L. Xu, and S. Zhu, “Phase transition mechanism of graphite to nano-polycrystalline diamond resolved by molecular dynamics simulation,” Chin. J. High Pressure Phys. 37, 041101 (2023).10.11858/gywlxb.20230663
[48]	T. Yu, S.-C. Zhu, and Y. Hou, “A novel sp3 carbon allotrope with 4 + 5 + 6 + 7 + 8 odd–even ring,” Phys. Chem. Chem. Phys. 26, 22182–22188 (2024).10.1039/d4cp01858c
[49]	K. Lonsdale, “Formation of lonsdaleite from single-crystal graphite,” Am. Mineral. 56, 333–336 (1971).
[50]	Y. Tateyama, T. Ogitsu, K. Kusakabe, and S. Tsuneyuki, “Constant-pressure first-principles studies on the transition states of the graphite-diamond transformation,” Phys. Rev. B 54, 14994–15001 (1996).10.1103/physrevb.54.14994
[51]	S.-D. Huang, C. Shang, P.-L. Kang, X.-J. Zhang, and Z.-P. Liu, “LASP: Fast global potential energy surface exploration,” Wiley Interdiscip. Rev.: Comput. Mol. Sci. 9, e1415 (2019).10.1002/wcms.1415
[52]	X.-J. Zhang and Z.-P. Liu, “Variable-cell double-ended surface walking method for fast transition state location of solid phase transitions,” J. Chem. Theory Comput. 11, 4885–4894 (2015).10.1021/acs.jctc.5b00641
[53]	C. Shang, X.-J. Zhang, and Z.-P. Liu, “Stochastic surface walking method for crystal structure and phase transition pathway prediction,” Phys. Chem. Chem. Phys. 16, 17845–17856 (2014).10.1039/c4cp01485e
[54]	C. Shang and Z.-P. Liu, “Stochastic surface walking method for structure prediction and pathway searching,” J. Chem. Theory Comput. 9, 1838–1845 (2013).10.1021/ct301010b
[55]	K. Luo, B. Liu, W. Hu, X. Dong, Y. Wang et al., “Coherent interfaces govern direct transformation from graphite to diamond,” Nature 607, 486–491 (2022).10.1038/s41586-022-04863-2
[56]	D. J. Erskine and W. J. Nellis, “Shock-induced martensitic phase transformation of oriented graphite to diamond,” Nature 349, 317–319 (1991).10.1038/349317a0
[57]	D. J. Erskine and W. J. Nellis, “Shock‐induced martensitic transformation of highly oriented graphite to diamond,” J. Appl. Phys. 71, 4882–4886 (1992).10.1063/1.350633
[58]	P. W. Chen, Y. S. Ding, Q. Chen, F. L. Huang, and S. R. Yun, “Spherical nanometer-sized diamond obtained from detonation,” Diamond Relat. Mater. 9, 1722–1725 (2000).10.1016/s0925-9635(00)00306-x
[59]	P. Chen, F. Huang, and S. Yun, “Characterization of the condensed carbon in detonation soot,” Carbon 41, 2093–2099 (2003).10.1016/s0008-6223(03)00229-x
[60]	M. R. Armstrong, H. B. Radousky, R. A. Austin, O. Tschauner, S. Brown et al., “Highly ordered graphite (HOPG) to hexagonal diamond (lonsdaleite) phase transition observed on picosecond time scales using ultrafast x-ray diffraction,” J. Appl. Phys. 132, 055901 (2022).10.1063/5.0085297
[61]	D. Kraus, A. Ravasio, M. Gauthier, D. O. Gericke, J. Vorberger et al., “Nanosecond formation of diamond and lonsdaleite by shock compression of graphite,” Nat. Commun. 7, 10970 (2016).10.1038/ncomms10970
[62]	S. J. Turneaure, S. M. Sharma, T. J. Volz, J. M. Winey, and Y. M. Gupta, “Transformation of shock-compressed graphite to hexagonal diamond in nanoseconds,” Sci. Adv. 3, eaao3561 (2017).10.1126/sciadv.aao3561
[63]	C. J. Mundy, A. Curioni, N. Goldman, I. F. Will Kuo, E. J. Reed et al., “Ultrafast transformation of graphite to diamond: An ab initio study of graphite under shock compression,” J. Chem. Phys. 128, 184701 (2008).10.1063/1.2913201
[64]	N. Pineau, “Molecular dynamics simulations of shock compressed graphite,” J. Phys. Chem. C 117, 12778–12786 (2013).10.1021/jp403568m
[65]	H. Sun, X. Jiang, R. Dai, L. Liu, Z. Wang et al., “Understanding the mechanism of shockwave induced graphite-to-diamond phase transition,” Materialia 24, 101487 (2022).10.1016/j.mtla.2022.101487
[66]	S.-c. Zhu, X.-z. Yan, J. Liu, A. R. Oganov, and Q. Zhu, “A revisited mechanism of the graphite-to-diamond transition at high temperature,” Matter 3, 864–878 (2020).10.1016/j.matt.2020.05.013
[67]	S.-C. Wei, G.-W. Chen, L. Xu, S.-C. Zhu, and Y. Hou, “3D twin formation mechanism from onion carbon,” J. Phys. Chem. C 128, 7652–7660 (2024).10.1021/acs.jpcc.3c08175
[68]	Y. Pan, X. Yuan, Y. Cheng, B. Xu, S. Liu et al., “Uniaxiality-induced reduced-pressure synthesis of ultrahard paracrystalline diamond,” Adv. Mater. 37, 2500037 (2025).10.1002/adma.202500037
