First results from a 760-GW linear transformer driver module for Z-pinch research

Chen Lin; Zou Wenkang; Jiang Jihao; Zhou Liangji; Wei Bing; Guo Fan; He An; Xie Weiping; Deng Jianjun; Wang Meng; Wang Jie; Zhang Yuanjun

doi:10.1063/5.0003346

Volume 6 Issue 4

Jul. 2021

Turn off MathJax

Article Contents

Article Navigation > Matter and Radiation at Extremes > 2021 > 6(4): 045901

Chen Lin, Zou Wenkang, Jiang Jihao, Zhou Liangji, Wei Bing, Guo Fan, He An, Xie Weiping, Deng Jianjun, Wang Meng, Wang Jie, Zhang Yuanjun. First results from a 760-GW linear transformer driver module for Z-pinch research[J]. Matter and Radiation at Extremes, 2021, 6(4): 045901. doi: 10.1063/5.0003346

Citation:

Chen Lin, Zou Wenkang, Jiang Jihao, Zhou Liangji, Wei Bing, Guo Fan, He An, Xie Weiping, Deng Jianjun, Wang Meng, Wang Jie, Zhang Yuanjun. First results from a 760-GW linear transformer driver module for Z-pinch research[J]. Matter and Radiation at Extremes, 2021, 6(4): 045901. doi: 10.1063/5.0003346

Citation:

Chen Lin, Zou Wenkang, Jiang Jihao, Zhou Liangji, Wei Bing, Guo Fan, He An, Xie Weiping, Deng Jianjun, Wang Meng, Wang Jie, Zhang Yuanjun. First results from a 760-GW linear transformer driver module for Z-pinch research[J]. Matter and Radiation at Extremes, 2021, 6(4): 045901. doi: 10.1063/5.0003346

PDF( 3276 KB)

First results from a 760-GW linear transformer driver module for Z-pinch research

doi: 10.1063/5.0003346

Key Laboratory of Pulsed Power, Institute of Fluid Physics, CAEP, Mianyang, China

More Information

Corresponding author: a)Author to whom correspondence should be addressed: 394560789@qq.com
Received Date: 2020-01-31
Accepted Date: 2021-05-03

Available Online: 2021-07-01

Publish Date: 2021-07-15

Abstract

Abstract

In this paper, the results of tests on a 0.76-TW linear transformer driver (LTD) module for Z-pinch research are presented for the first time. Ten LTD cavities, each generating a 1-MA/90-kV pulse on a matched load, were connected in series with a magnetically insulated voltage adder to drive the e-beam diode. Three inner stalks with different radii were tested, and the results indicate that the output parameters of the ten cavities are sensitive to the cathode radii. As an intermediate step, a high-current pulse with 832 kV/912 kA/130 ns was obtained on the e-beam diode. To date, this is the maximum power generated directly by a fast LTD with mega-ampere current output.
