Development of new diagnostics based on LiF detector for pump-probe experiments

doi: 10.1016/j.mre.2018.01.006
More Information
  • Corresponding author: *Corresponding author. Open and Transdisciplinary Research Initiatives, Osaka University, Suita, Osaka 565-0871, Japan. E-mail address: pikuz-tatiana@gmail.com (T. Pikuz).
  • Received Date: 2017-07-20
  • Accepted Date: 2018-01-08
  • Available Online: 2021-12-07
  • Publish Date: 2018-07-15
  • We present new diagnostics for use in optical laser pump - X-ray Free Electron Laser (XFEL) probe experiments to monitor dimensions, intensity profile and focusability of the XFEL beam and to control initial quality and homogeneity of targets to be driven by optical laser pulse. By developing X-ray imaging, based on the use of an LiF crystal detector, we were able to measure the distribution of energy inside a hard X-ray beam with unprecedented high spatial resolution (∼1 μm) and across a field of view larger than some millimetres. This diagnostic can be used in situ, provides a very high dynamic range, has an extremely limited cost, and is relatively easy to be implemented in pump-probe experiments. The proposed methods were successfully applied in pump-probe experiments at the SPring-8 Angstrom Compact free electron LAser (SACLA) XFEL facility and its potential was demonstrated for current and future High Energy Density Science experiments.
